Motorized Card Reader,motor Card Reader,CRT-350-N
CRT-350-N motorized card reader is designed based on the development concept that integrates multiple functions. Careful material selection, rational structure and stable circuit design make it a highly reliable product,all these enable CRT-350-N to better meet the market requirements for motorized card reader/writer.
CRT-350-N motorized card reader product feature
Mechanical shutter for protection against dust and/or the other foreign materials in the bezel position: enhances the reliability of the card reader
High-end ATM-oriented motor-driven card reader for magnetic card,contact IC card
Front-rear card-in card-out,jittery card-in control
Support DES,3DES,AES & Chinese commercial encryption algorithm
Optional anti-skimming,anti fishing function by eletromagnetic wave interference
CRT-350-N motorized card reader product specification
Card type | Magnetic card ISO7810,ISO7811 Loco 300oe support writing loco 300oe Writing Hico optional IC card ISO7816-1,2,3 Support T=0、T=1 CPU card Support T=0、T=1 PSAM card Support R/W RFID card (optional) |
Card dimension | Width:53.92~54.18mm Length:85.47~85.90mm Thickness:0.76±0.08mm |
| Power supply | DC24V±10% |
| Communication interface | RS-232/USB (HID) |
| Operation current (without solenoid current) | Idle<250mA Peak<3000mA |
| Magnetic head | 1,000,000cycles |
| IC card contact | 300,000 cycles |
| Drive parts | 1,000,000cycles |
| Weight | about 1.3kg |
CRT-350-N motorized card reader product application
ATM/CRS
Self-service terminal
Self-service recharging payment machine recharger
Parking system
Security terminal
