RFID Card Dispenser CRT-571
Based on reliable structure design and massive integrated circuit, CRT-571 specially supports automatic card dispensing (collecting) which function controlled card dispensing & collecting and RF card operation. Transmitting power by stepper motor, properties with high speed, high stability, highly reliability and long working lifetime.
RFID card issuing machine CRT-571 product feature
Compact, high reliability and durability
Support contactless IC card (ISO14443 TYPE A & B)-optional
Support S50 & S70 (Mifare) card (ISO14443 TYPE A & B)
Designed with shutter, dust and water proof
Adjustable card thickness & dispensing speed
Extension stackable cards hopper capacity:500pcs (card thickness: 0.76mm)
With multi bezel (Optional)
Various correspondingand custom design
RFID card issuing machine CRT-571 product specification
Card type | IC card ISO7816-1,2,3,4 Support T=0、T=1 CPU Card RFID card ISO14443 Type A & B Support Mifare 1 S50,S70,UL card Mifare Pluse,Mifare Desfire |
Card dimension | Width:53.92~54.18mm Length:85.47~85.90mm |
| Communication interface | RS-232 |
| Power supply | DC 24V±5% |
Operation current | Idle :<200mA Peak :<1500mA |
Load option | Short removable stacker 240pcs Long removable stacker 500pcs |
| Card volume alarm | 7~50pcs ± 2pcs |
| Card speed | > 1pcs/s |
RFID card issuing machine CRT-571 product application
Parking management system
Automatic card-vending machine
Hotel self-service card-issuing system
Card batch initialization
Telcom/Power self-service system for openning account & dispensing card
