Smart Card Dispenser CRT-541 For Gaming Machine
CRT-541 card dispenser is upgraded from CRT-540. It performs more stable and reliable but is compatible with CRT-540 in all aspects with optional TTL and RS232 interface for self service kiosk,Gaming machine, SOHO office, self service parking lot etc.
Smart card dispenser CRT-541 product feature
Pre-issuing capabilites to speed up card dispensing
Unique design for dispensing paper card
Easy adjustment of card thickness
Easy card loading & maintenance
Support ISP download on-line
Support multi-units communication
Card stacker empty and pre-empty detection
Pre-Card dispensing function
Iron-Block available to fit
RoHS standard compliant
Smart card dispenser CRT-541 product specification
| Power Supply | DC 24V ±5% |
Current Consumption | Static Current: 0.1A Peak Current During Operation: 1.5A Normal Current Condition: 800mA |
| Card Feeding-Out Speed | > 1Cards/s |
| Communication Interface | RS232C, TTL (customized) |
Card Dimensions | Size: 55mm×86mm Thickness: ≥0.20mm (≥1.2mm require customization ) Ex-work standard card thickness is 0.8 mm |
| Weight | 2.0 Kg Approx |
Environmental Condition | Operation: 0~50℃ 0~90% RH ( Without Condensing) Storage:-10~75℃ 0~90% RH ( Without Condensing) |
Smart card dispenser CRT-541 product application
Automatic vending machine
Gaming machine
Subway or public transport card issue
Ticket-vending system
Prepaid card-vending system
Parking system
