Traffic Flow Millimeter Wave Radar CRT-RT501-001
CREATOR is a leading China Millimeter Wave Radar manufacturer and factory, welcome to wholesale high-end economic and cheap OEM and ODM traffic flow millimeter wave radar crt-rt501-001 from us.
Traffic Flow Millimeter Wave Radar
Designed for high-speed traffic monitoring and urban traffic light control. Detects violations (e.g., illegal parking, speeding) within 350 meters, tracks vehicle trajectories in real time, and provides speed data. Enables instant traffic insights to identify congestion and anomalies.
Main Features
Not affected by external interference such as sunlight, dust, rain, snow, or haze
Multi-lane coverage
Supports 8 lanes
01
Multi-target tracking
Up to 200 targets
02
Long-range detection
350m maximum
03
Wide speed range
±337.5 km/h
04
Multi-interface
RJ45, RS485, CAN
05
Products Specification
| Modulation | FMCW |
| Detection Range | 350m |
| Range Resolution | 1.4m |
| Range Accuracy | ±0.2m |
| Angular Accuracy | ±0.5°@0° |
| Angular Resolution | 2.0°@0° |
| Speed Range | ±337.5km/h |
| Speed Resolution | 0.2km/h |
| Speed Accuracy | ±0.05km/h |
| Lane Detected | 8 |
| Target Tracked | 200 |
| Update Rate | 10Hz |
| Antenna Channel | 4TX/4RX=16 channels |
| Operation Frequency | 79...81GHz |
| Transmission | 33dBm |
| Voltage | 9.0-36V DC |
| Power Consumption | ＜4.6W@12V |
| Working Temp | -40°C-85°C, 0 ~ 95 % RH (non-condensing) |
| Storage Temp | -40°C-105°C, 0 ~ 95 % RH (non-condensing) |
| Dimensions | 99mm*79mm |
| Communication | RJ45/RS485/CAN |
