Through the palm print palm vein data and registration data comparison identification to complete the personal identity authentication, while supporting the QR code recognition function.

Send Inquiry

Product Introduction

Products Description

PRM-001 palm print palm vein recognition module through the palm print palm vein data and registration data comparison identification to complete the personal identity authentication, while supporting the QR code recognition function.

This module adopts a high-performance ARM processing unit, which features fast recognition speed, high precision, and anti-counterfeiting detection. It can be used in gates, access control, time and attendance, human ID detection, shops and public transport collection, and other scenes.

Products Features

FAR (False Alert Rate) is less than 1 in 100 million; FRR (Failure to Recognise Rate) is less than 1 in 10,000
Integrated quad-core GPU and high-performance NPU, palm recognition speed is less than 450ms
Supports up to 4GB of LPDDR4 memory and32GB of EMMC storage
Low power consumption, passive cooling with no holes design, dustproof and waterproof IP54
High-performance brush palm recognition camera system with high-performance ISP dedicated processor, high imaging quality and high precision of live body detection
Supports extremely fast completion of QR code scanning 45ms (450 bytes QR code), large viewing angle image sensor scanning
Support object self-sensing, object recognition, auto-sensing fill light adjustment
The key chips are all domestically designed and controlled by independent research and development
Security: non-contact acquisition; prevention of palm photo imitation attacks; encrypted data transmission, financial industry security encryption algorithm identification
Simple and beautiful, structural design is not constrained by the existing equipment structure, greatly reducing the difficulty of equipment transformation and maintenance
Wide range of application: can be adapted to multiple types of gates, a variety of scenes to us

Products specification

Power	DC12V 30W(Max)
CPU	Quad-core 32-bit ARM Cortex-A7, RISC-V MCU up to 1.5GHz
GPU	ARMMali-G610 MP4 Quad-core
NPU	NPUpower up to 2 TOPS
RAM ROM	Supports up to 4GB LPDDR4 RAM, 32GB EMMC storage, (1+8GB standard)
Camera	RGB+IR camera with support for fast AE exposure control, FOV H116°x V95°
Brush Palm Function	Built-in distance detection sensor, 7cm~15cm distance range to brush the palm to use, Support dark light and backlight scene recognition, support 360-degree all round recognition
Reading Code	1D code, 2D code QRCODE, DATAMATRIX, etc.
Average Decoding Time	35ms (300 byte QR code); 45ms (450 byte QR code)
Barcode Accuracy	≥3.9 mil
Extended Interface	NFC interface, second generation ID card interface, Bluetooth module interface, 2.4GHz module interface (optional)
Sound And Light System	Fill light and 3-colour cue light with LED technology, buzzer support, loudspeaker
Communication Interface	RS232 interface x 1, 1000Mbps Ethernet RJ45, USB-C multi-function interface x 1
Environmental Sealing Class	IP54
Firmware Upgrade	Supports OTA upgrade, motherboard temperature and SOC temperature reporting
Installation Method	Supports desktop, wall-mounted and flush-mounted installation
