Triple-Lens Auto-Tracking PTZ Camera Module GDZS-DC004-AP07

5MP Panoramic + 3MP Visible + 2MP IR

Send Inquiry

Product Introduction

Products Description

The GDZS-DC004-AP07 redefines precision security with triple-spectrum imaging and AI-powered tracking. Combining 5MP panoramic oversight, 3MP visible clarity, and 2MP infrared liveness detection, it delivers unmatched facial recognition accuracy in dynamic environments. Featuring motorized PTZ auto-tracking, commercial-grade encryption, and wide dynamic imaging, this agile camera ensures tamper-proof identity verification for high-stakes applications-from secure access and financial services to smart surveillance and automated systems.

Products Features

Triple-spectrum Imaging

5MP Panoramic (2592×1944): Complete environmental oversight
3MP Visible (2048×1536): High-definition clarity for facial details
2MP IR (1920×1080): Reliable liveness detection day or night

Intelligent Active PTZ Tracking

Auto-tracks subjects vertically (±30°), optimized for heights 1.4–1.9m (seated/standing)
Rapid ≤2s response time
Focus-triggered face identification

Commercial-grade Security

Dedicated encryption chip supporting critical security algorithms
Ensures end-to-end data integrity and tamper resistance

Superior Image Quality

Wide Dynamic Range (WDR): ≥85dB (Visible/Panoramic) | ≥68dB (IR)
Maintains clarity in extreme conditions: 12,000LUX backlight to 15LUX low light
Optimized for facial recognition 40–120cm from the lens

Anti-spoofing & Processing

Active Infrared Liveness Detection (850nm)
Real-time auto-exposure, anti-flicker, and anti-shake
Strict pixel alignment (<15 points) for algorithm-resistant security

Universal USB 2.0 Plug-and-Play

Seamless integration with Windows, Android, Mac Linux 6.2 embedded systems
Enables rapid deployment

Products application

1-Dual-Lens Face Recognition Camera Module GDZS-DC004-ESBVTN 1

Banking & Finance

Revolutionizing ATM Security

2-Dual-Lens Face Recognition Camera Module GDZS-DC004-ESBVTN 3

Smart Retail

Autonomous Kiosks, Effortless Experience

3-Dual-Lens Face Recognition Camera Module GDZS-DC004-ESBVTN 2

Gaming & Leisure

Player-centric Intelligence

Products specification

Imaging Specifications

Parameter	Visible Light	Infrared (IR)	Panoramic
Sensor	1/2.5" CMOS	1/2.5" CMOS	1/2.5" CMOS
Resolution	2048×1536 (3MP)	1920×1080 (2MP)	2592×1944 (5MP)
Max Frame Rate (MJPG)	2048×1536@25fps	1920×1080@30fps	2592×1944@30fps
Max Frame Rate (YUY2)	2048×1536@3fps	1920×1080@5fps	2592×1944@2.5fps
SNR	≥40dB	≥40dB	≥50dB
Lens FOV (H/V)	73°±5% / 55°±5%	73°±5% / 55°±5%	130°(H) / 150°(D)
